2024 Corvette E-Ray Convertible Specifications, Options and Production Numbers

Explore comprehensive Corvette specifications, production numbers, options, and color codes by model year. Your complete reference for authentic restoration and research.

Available Body Styles:

Stingray Coupe Stingray Convertible E-Ray Coupe E-Ray Convertible Z06 Coupe Z06 Convertible

Production & Specifications

Total Production

818

Wheelbase

107.20"

Length

176.90"

Width

76.10"

Height

48.60"

Curb Weight

3,856.00 lbs.

Track Front/Rear

64.90" / 62.40"

Tire Size

P275/30ZR-20

Plant Built

Bowling Green

Base Engine

6.2L LT2 V8 with e-AWD

Serial Range

1G1YF3D0XR5TBD - 1G1YF3D0XR5TBD

Total Production	818
Wheelbase	107.20"
Length	176.90"
Width	76.10"
Height	48.60"
Curb Weight	3,856.00 lbs.
Track F/R	64.90" / 62.40"
Tire Size	P275/30ZR-20
Plant Built	Bowling Green
Base Engine	6.2L LT2 V8 with e-AWD
Serial Range	1G1YF3D0XR5TBD - 1G1YF3D0XR5TBD

→

📱 Rotate device for better viewing

Options for Model Year 2024, E-Ray Convertible

* = Option price during model year
** = Option price adjusted for inflation, in 2025 dollars

Code	Description	Quantity	2024*	2025**
1LZ	Equipment Group	19	$0	$
1YG67	ERay Conv	818	$113,595	$117,003
255	GREEN	18	$0	$
2LZ	Equipment Group	193	$8,900	$9,167
36S	YELLOW STITCHING	24	$0	$
379	ORANGE	11	$0	$
38S	RED STITCHING	99	$0	$
3A9	BLUE	100	$0	$
3F9	RED	190	$0	$
3LZ	Equipment Group	606	$13,550	$13,957
3M9	YELLOW	42	$0	$
3N9	TAN	41	$0	$
4AA	BLACK	307	$0	$
4BZ	ADR RED DIPPED	32	$0	$
4G2	BLACK/ADRENALINE	146	$0	$
4JE	TWILIGHT BLUE/TENS	79	$0	$
4JF	BLACK/SKY COOL	115	$0	$
4JG	ARTEMIS	18	$0	$
4JH	BLACK/NATURAL	78	$0	$
4JY	NATURAL DIPPED	43	$0	$
5BX	Roof Panel Vis CF	n/a	$0	$
5DG	Tech Bronze Wheels	n/a	$0	$
5DH	Satin Graphite Z06	n/a	$0	$
5DK	Tech Bronze Z06 wh	n/a	$0	$
5DO	Bright Polished St	n/a	$0	$
5JR	Visible CF Mirror	37	$1,285	$1,324
5V5	High Wing Spoiler	1	$5,995	$6,175
5V7	Ground Effects Bla	n/a	$720	$742
5VM	Ground Effects Vis	n/a	$0	$
5W8	Ground Effects Car	n/a	$0	$
5YQ	Roof Panel Vis CF	n/a	$0	$
5ZC	Wheel Cap Jake Log	42	$260	$268
5ZD	Wheel Cap w/Cross	17	$260	$268
5ZU	High Wing Spoiler	n/a	$1,250	$1,288
5ZW	Stanchion Wing Sti	n/a	$0	$
5ZZ	High Wing Spoiler	n/a	$1,350	$1,391
719	BLACK	416	$0	$
AE4	GT2 SEAT	70	$1,995	$2,055
AH2	GT2 BODY CONTOUR	669	$0	$
AQ9	LUXURY SEAT	79	$0	$
B4Z	PERF PKG TRACTION	818	$0	$
BAZ	BLACKOUT PKG	314	$595	$613
BV4	DEDICATION	25	$295	$304
C2M	VISIBLE CARBON	n/a	$0	$
C2Q	TWO TOP PKG	n/a	$0	$
C2Z	VISIBLE CARBON	n/a	$2,495	$2,570
CAV	Frunk Liner	40	$0	$
CC3	TRANSPARENT	n/a	$0	$
CF7	PAINTED BODY COLOR	n/a	$0	$
CFV	VIS CF ROCKER SPLI	183	$3,995	$4,115
CFX	MUSEUM LOGO w/R8C	32	$0	$
CFZ	PTD ROCKER SPLITTE	161	$2,995	$3,085
D30	COLOR OVERRIDE	20	$695	$716
D3V	LAMP ENG COMP	n/a	$100	$103
D58	SPOILER NONE	1	$0	$
D84	CARB FLASH ROOF AN	352	$0	$
D86	BODY COLOR ROOF AN	68	$0	$
DPB	CARB FLSH RCNG BLU	3	$0	$
DPC	CARB FLSH RCNG YEL	3	$0	$
DPG	CARB FLSH RCNG ORN	n/a	$0	$
DPL	CARB FLSH RCNG FUL	12	$0	$
DPT	CARN FLSH RCNG SIL	7	$0	$
DRG	CARBON	312	$0	$
DSY	EDGE ORANGE FULL	1	$995	$1,025
DSZ	EDGE RED FULL	2	$995	$1,025
DT0	EDGE YELLOW FULL	1	$995	$1,025
DTB	RACING BLUE VAR 1	26	$0	$
DTH	CARB FLASH FULL	27	$995	$1,025
DUB	STERLING SILVER FU	14	$995	$1,025
DUW	EDGE BLUE FULL	3	$995	$1,025
DZU	CF EDGE YELLOW STI	3	$500	$515
DZV	CF MIDNIGHT SILVER	2	$500	$515
DZX	CF EDGE RED STING	5	$995	$1,025
E60	FRONT LIFT	611	$2,595	$2,673
EFA	DK SHADOW METALLIC	n/a	$995	$1,025
EFR	CARBON FLASH	271	$0	$
EFY	BODY COLOR	547	$0	$
ERI	BATTERY PACK	335	$100	$103
EYK	EMBLEM-CHROME	71	$0	$
EYT	EMBLEM-CARBON	747	$0	$
FA5	MIN HIGH GLOSS LH	105	$2,495	$2,570
FA5r	MIN HIGH GLOSS RHD	1	$2,495	$2,570
FA6	MAX HIGH GLOSS LHD	156	$1,285	$1,324
FE1	STANDARD SUSP	n/a	$0	$
FE2	MAG RIDE NON-Z51	n/a	$0	$
FE3	GT2 SUSP Z51	n/a	$0	$
FE4	RIDE & HDG Z51	n/a	$0	$
FE5	RIDE & HLG HP1	333	$0	$
FE6	RIDE & HLG Z06	n/a	$0	$
FE7	PERF Z06	n/a	$0	$
FE9	FEDERAL CERT	595	$0	$
FED	RIDE & HLG VAR 5	485	$0	$
G0J	AXLE REAR 4.89	n/a	$0	$
G0K	AXLE REAR 5.56	n/a	$0	$
G8G	ARCTIC WHITE	128	$0	$
G96	eLSD	818	$0	$
G9F	CERAMIC MATRIX GRA	25	$0	$
GA7	HYPERSONIC GRAY	26	$0	$
GAR	CARBON FLASH	27	$0	$
GBA	BLACK	74	$625	$644
GC5	AMPLIFY ORANGE	16	$995	$1,025
GD0	ACCELERATE	19	$500	$515
GJV	RIP TIDE MET	96	$0	$
GKZ	TORCH RED	91	$0	$
GM7	AXLE REAR 5.17	818	$0	$
GMO	RAPID BLUE	34	$0	$
GPH	RED MIST	106	$0	$
GSJ	SILVER FLARE	39	$0	$
GVR	CACTI SOLID	39	$0	$
GXA	SEA WOLF TRI MET	98	$0	$
HMO	OR BLK INT/GRAY S	12	$0	$
HNK	ADR RED DIPPED LTH	32	$0	$
HTA	BLK LTHR LV1	34	$0	$
HTE	BLACK GT2 LV3	124	$0	$
HTG	NATURAL SUEDE GT2	8	$0	$
HTJ	BLK CLOTH AE4 LV	3	$0	$
HTM	BLK LTHR LV2	30	$0	$
HTN	NATURAL GT2 LV2	17	$0	$
HTO	TWO TONE BLUE LTHR	79	$0	$
HTP	BLK SUEDE AH2 LV	12	$0	$
HTQ	NATURAL SUEDE GT2	4	$0	$
HTT	BLACK SUEDE GT2	57	$0	$
HU0	OR BLK INT/ADR RE	10	$0	$
HU1	GRAY GT2 LV3	52	$0	$
HU2	ADR RED GT2 LV3	43	$0	$
HU6	GRAY SUEDE GT2 LV	9	$0	$
HU7	ADR RED SUEDE GT2	14	$0	$
HU9	GRAY SUEDE GT2 LV	23	$0	$
HUA	ADR RED SUEDE GT2	37	$0	$
HUE	NATURAL GT2 LV3	35	$0	$
HUF	NATURAL DIPPED SUE	12	$0	$
HUK	GRAY GT2 LV2	13	$0	$
HUL	ADR RED GT2 LV2	31	$0	$
HUN	GRAY GT1 LV2	10	$0	$
HUP	GRAY LTHR LV1	3	$0	$
HUQ	ADR RED LTHR LV1	3	$0	$
HUR	ADR RED GT1 LV2	15	$0	$
HUU	OR ADR RED INT/BL	1	$0	$
HUV	NATURAL GT1 LV2	14	$0	$
HV2	LEATHER LV 3.2	18	$0	$
HVT	OR BLK INT/GRAY S	2	$0	$
HVV	OR BLK INT/GRAY S	6	$0	$
HXO	OR BLK INT/ADR RE	19	$0	$
HZB	OR BLK INT/GRAY S	3	$0	$
HZN	NATURAL GT2 LV3	31	$0	$
HZP	OR ADR RED INT/BL	2	$0	$
IOK	RADIO INFOTAINMENT	818	$0	$
IWE	WRAP SUEDE INT	606	$0	$
J55	HEAVY DUTY	n/a	$0	$
J56	HD Z06	n/a	$0	$
J57	BRAKES, FREE FLOW	818	$0	$
J57c	BRAKES, CERAMIC	818	$0	$
J6A	CALIPER BLACK	n/a	$0	$
J6D	CALIPER DK GRAY	315	$0	$
J6E	CALIPER YELLOW	81	$695	$716
J6F	CALIPER RED	264	$695	$716
J6L	CALIPER ORANGE	20	$0	$
J6N	CALIPER EDGE RED	138	$695	$716
JL9	FRT/RR DISC	n/a	$0	$
LHD	Left Hand Drive	817	$0	$
LT2	6.2L	818	$0	$
LT6	5.5L	n/a	$0	$
M1L	8 SPD DCT	n/a	$0	$
M1M	8 SPD	n/a	$0	$
MAN	IFOLD APPEARANCE FI	n/a	$0	$
MLH	8 SPD DCT ATSS	818	$0	$
N26	SUEDE	42	$0	$
N2Z	SUEDE 3SPOKE	172	$0	$
N3W	LEATHER 3SPOKE	434	$0	$
NE1	NORTHEAST CERT	147	$0	$
NGA	BLACK TIPS	468	$395	$407
NK4	GT2 LTHR	170	$0	$
NPP	PERFORM EXHAUST	818	$1,195	$1,231
NTB	FEDERAL	607	$0	$
NUB	CALI	n/a	$0	$
NUF	CALI	203	$0	$
NWI	BRIGHT TIPS	350	$0	$
Q8P	BRIGHT SILVER	n/a	$0	$
Q8Q	PAINTED CARB FLASH	n/a	$995	$1,025
Q99	ULTRA BR MACHINED	n/a	$1,995	$2,055
Q9A	CARB FLASH W/RED	n/a	$1,495	$1,540
Q9I	GLOSS BLACK	n/a	$995	$1,025
Q9O	SATIN GRAPHITE	n/a	$995	$1,025
Q9Y	UBM STER SILV	n/a	$1,495	$1,540
R8C	MUSEUM DELIVERY	32	$995	$1,025
RHD	Right Hand Drive	1	$0	$
RIA	Floor Liners	86	$205	$211
RIK	Rear Script - Red	24	$0	$
RIN	Rear Script - Whit	3	$0	$
RNX	Veh Cover Stingray	n/a	$0	$
ROU	PEARL NICKEL	144	$0	$
ROX	MET GROOVED	154	$0	$
ROY	CARB FBR PAINTED Z	37	$11,995	$12,355
ROZ	CARB FIB VISIBLE Z	67	$11,995	$12,355
RWH	Veh Cover Indoor B	55	$0	$
RWJ	Veh Cover Crossfla	n/a	$0	$
RWL	RWD	n/a	$0	$
RWU	Cargo Organizer	8	$0	$
RXH	Center Cap Silver	n/a	$0	$
RXI	CF Engine Cover	n/a	$2,195	$2,261
SOA	BLACK	n/a	$0	$
SOC	SATIN GRAPHITE	n/a	$0	$
SOD	MACHINED FACE	n/a	$0	$
SOE	TITANIUM SATIN - S	n/a	$0	$
SOM	FULLY POLISHED	165	$0	$
SON	HIGH GLOSS BLACK	215	$0	$
STZ	CARBON RED STRIPE	36	$15,500	$15,965
T0A	AERO	n/a	$0	$
T0F	CARB FIBER PAINTED	n/a	$8,495	$8,750
T0G	CARB FIBER EXPOSED	n/a	$10,495	$10,810
T0M	AERO	n/a	$0	$
TU7	TWO TONE SEATS	186	$595	$613
TVS	LOW PROFILE SPOILE	n/a	$595	$613
UE1	ONSTAR	809	$0	$
UG1	UNV GARAGE DOOR	786	$0	$
UQT	VEH PERF RECORDER	800	$1,795	$1,849
V08	HD COOLING	818	$0	$
VK3	FRONT LIC PLT	387	$0	$
XFD	eAWD	818	$0	$
XFN	ALL SEASON TIRE	n/a	$0	$
XFQ	Z51 TIRE	n/a	$0	$
XFR	PS 4S TIRE	492	$0	$
XFS	CUP 2 R TIRE	n/a	$0	$
XFT	ALL SEASON TIRE	326	$0	$
YF5	CA CERT	56	$0	$
Z07	PERF PKG	n/a	$8,995	$9,265
Z51	PERF PKG	n/a	$6,345	$6,535
ZER	PERF PKG	485	$8,995	$9,265
ZF1	AERO DELETE Z51	n/a	$0	$
ZTK	PERF PKG	n/a	$5,995	$6,175
ZYC	CARBON FLASH ACCEN	283	$260	$268
ZZ3	APPEARANCE	222	$995	$1,025

Paint Colors for Model Year 2024, E-Ray Convertible

Code	Description	Quantity	Additional Charge
B8G	Artic White	128	$0.00
G9F	Ceramic Matrix Gray Metallic	25	$0.00
GA7	Hypersonic gray	26	$0.00
GAR	Carbon Flash Metallic	27	$0.00
GBA	Black	74	$0.00
GC5	Amplify Orage	16	$0.00
GD0	Accelerate Yellow	19	$0.00
GJV	Riptide Blue Metallic	96	$0.00
GKZ	Torch Red	91	$0.00
GMO	Rapid Blue	34	$0.00
GPH	Red Mist	106	$0.00
GSJ	Silver Flare Metallic	39	$0.00
GVR	Cacti Green	39	$0.00
GXA	Sea Wolf Grey Tricoat	98	$0.00
