2009 Corvette Convertible Specifications, Options and Production Numbers

Explore comprehensive Corvette specifications, production numbers, options, and color codes by model year. Your complete reference for authentic restoration and research.

Available Body Styles:

Coupe Convertible Z06 ZR1

Production & Specifications

Total Production

3,343

Wheelbase

105.70"

Length

174.60"

Width

72.60"

Height

49.00"

Curb Weight

3,222.00 lbs.

Track Front/Rear

62.10" / 60.70"

Tire Size

FT: P275/35ZR18; RR: 325/30ZR19

Plant Built

Bowling Green

Base Engine

6.2L V-8 LS3

Serial Range

n/a

Total Production	3,343
Wheelbase	105.70"
Length	174.60"
Width	72.60"
Height	49.00"
Curb Weight	3,222.00 lbs.
Track F/R	62.10" / 60.70"
Tire Size	FT: P275/35ZR18; RR: 325/30ZR19
Plant Built	Bowling Green
Base Engine	6.2L V-8 LS3
Serial Range	n/a

Detailed Engine & Chassis Specifications

Engine Details

Bore & Stroke

4.06 x 3.62

Block Material

cast aluminum

Cylinder Head Material

cast aluminum

Valvetrain

OHV, 2 valves per cylinder

Fuel Delivery

sequential EFI

Compression Ratio

10.7:1

Recommended Fuel

93 octane (recommended but not required)

Fuel Economy

Auto:15/25; Man:16/26

Transmission Type

6-speed manual/6-speed paddle-shirt auto

Chassis & Suspension

Chassis, Front

short/long arm ( SLA ) double wishbone, cast aluminum upper & lower control arms, transverse-mounted composite leaf spring, monotube shock absorber

Chassis, Rear

short/long arm ( SLA ) double wishbone, cast aluminum upper & lower control arms, transverse-mounted composite leaf spring, monotube shock absorber

Traction Control

electronic traction control; Active Handling

Brakes & Wheels

Brakes Type

ft and rr power-assisted disc with ABS; cross-drilled rotors with Z51 pkg and Magnetic Ride Control

Brake Rotor Size

ft: 12.8 x 1.26; rr: 12 x 1; Z51 Performance Package: ft: 13.4 x 1.26; rr: 13 x 1

Wheel Size

front: 18 inch x 8.5 inch; rear: 19 inch x 10 inch

→

📱 Rotate device for better viewing

Options for Model Year 2009, Convertible

* = Option price during model year
** = Option price adjusted for inflation, in 2025 dollars

Code	Description	Quantity	2009*	2025**
1YY67	Base Corvette Convertible	3,343	$0	$
2LT	Option Package	238	n/a	n/a
3LT	Option Package	1,974	n/a	n/a
4LT	Option Package	307	n/a	n/a
AAB	Memory Package	2,413	n/a	n/a
AQ9	Seats, Sport front bucket	3,102	n/a	n/a
AR9	Seats, front bucket with leather seating surfaces,	241	n/a	n/a
C05	Manual Convertible Top	245	n/a	n/a
CM7	Convertible top, power folding,	3,098	n/a	n/a
D30	Color Combination Override	38	n/a	n/a
DD0/DD8	Electrochromatic and Heated Mirrors	3,343	n/a	n/a
F55	Magnetic Selective Ride Control,	1,126	n/a	n/a
FE1	Suspension, 4-wheel independent	1,218	n/a	n/a
FE2	RTD Suspension (req'd w/F55 on Base)	1,126	n/a	n/a
FE3	Sport Ride Suspension	999	n/a	n/a
FE9	Emissions, Federal requirements	2,144	n/a	n/a
GM8	Rear Axle Ratio - 2.56	1,658	n/a	n/a
GT1	Specialty: GT1	17	n/a	n/a
GU2	Rear axle, 2.73 ratio, limited-slip,	1,080	n/a	n/a
GU6	Rear axle, 3.42 ratio	605	n/a	n/a
J55	Heavy Duty Brakes	2,125	n/a	n/a
KA1	Seats, heated driver and front passenger	2,385	n/a	n/a
KNP	Transmission Cooler	296	n/a	n/a
KNR	Axle Cooler	69	n/a	n/a
KPS	Engine Oil Cooler	356	n/a	n/a
LS3	Engine, 6.2L V8 SFI	n/a	n/a	n/a
MM6	Transmission, 6-speed manual	309	n/a	n/a
MX0	Transmission, 6-speed paddle shift with automatic modes	2,738	n/a	n/a
MZ6	Six-speed Manual Transmission w/Z51	296	n/a	n/a
N37	Steering column, power telescopic with manual tilt	2,374	n/a	n/a
NPP	Exhaust, dual-mode, performance,	2,033	n/a	n/a
Q9V	Wheels, 5-spoke, forged chrome aluminum,	1,891	n/a	n/a
QG6	Wheels, 5-split spoke, Silver-painted aluminum	502	n/a	n/a
QG7	Wheels, 5-spoke, forged polished aluminum,	492	n/a	n/a
QX1	Wheels, 5-split spoke, Competition Gray-painted aluminum	83	n/a	n/a
R8C	Corvette Museum Delivery	83	n/a	n/a
SLL	Sold Orders	668	n/a	n/a
SLM	Stock Orders	2,168	n/a	n/a
U2K	XM Radio	3,274	n/a	n/a
U3U	Audio system with navigation	1,632	n/a	n/a
U65	Premium Bose Speaker System	2,413	n/a	n/a
U66	Base Speaker System	930	n/a	n/a
UE1	OnStar, 1-year of Safe and Sound plan	3,274	n/a	n/a
UG1	Universal Home Remote,	2,344	n/a	n/a
UPF	Bluetooth for phone	3,029	n/a	n/a
US8	Audio system, AM/FM stereo with CD player and MP3 playback	930	n/a	n/a
US9	Audio system	779	n/a	n/a
UV6	Head-Up Display	2,413	n/a	n/a
VDN	Indoor Vehicle Cover (LPO)	24	n/a	n/a
VEB	Pedal Covers (LPO)	34	n/a	n/a
VJ5	Outdoor Vehicle Cover (LPO)	10	n/a	n/a
VPK	Limited Personalization Option	26	n/a	n/a
VPL	Limited Personalization Option	403	n/a	n/a
Z51	Z51 Performance Package,	999	n/a	n/a
ZHZ	Specialty: Hertz (all yellow)	375	n/a	n/a

Paint Colors for Model Year 2009, Convertible

Code	Description	Quantity	Additional Charge
10U	Arctic White	260	$0.00
17U	Blade Silver Metallic	269	$0.00
41U	Black	560	$0.00
45U	Velocity Yellow Tintcoat	565	$750.00
57U	Cyber Gray Metallic	393	$0.00
74U	Victory Red	369	$0.00
83U	Atomic Orange Metallic	91	$300.00
85U	Jetstream Blue Metallic Tintcoat	191	$750.00
89U	Crystal Red Metallic Tintcoat	645	$750.00
